Welcome to AMCOM

Established in December 1996, AMCOM is a leading edge microwave design organization that provides power FETs, MMIC power amplifiers, as well as high-power amplifier modules with RF and DC connectors.

Click on 'Products' or download the following guide to view detailed listings of available products.

Product Selection Guide

Representative Products

icon New Products

Discrete Power GaN HEMTs

Part Number Freq(GHz) Gss(dB) P5dB(dBm) PAE@P5dB Vds ECCN S-parameters
AM050WN-CU-R* DC-6 16dB 43dBm 55% 28V EAR99 download
AM100WN-CU-R* DC-6 14dB 46dBm 50% 28V EAR99 download
AM025WN-BI-R* DC-8 16dB 40dBm 52% 28V EAR99 download
AM012WN-BI-R* DC-10 17dB 37dBm 51% 28V EAR99 download
AM005WN-BI-R DC-12 15dB 33.5dBm 51% 28V EAR99 download

Universal Modules

Model Freq(GHz) Gain(dB) P1dB(dBm) P3db(dBm) Eff(%) DC bias(V) ECCN
AM206541UM-3H* 2.0-6.5 26 38 41 20 28 EAR99

Power Amplifier Modules

Model Freq(GHz) Gain(dB) P5db(W) IP3(dBm) Eff(%) Vd(V) Idq(A) Size(in)
AM206545SF-3H 2.6-6.5 28 31 47 20 32 2.5 4x3.18x0.56
AM07512043SF-2H 7.5-12 19 20 47 15 32 2.5 4x3.08x0.56
AM608038SF-3H 6-8 26 8 45 15 32 0.75 4.0x3.2x0.75
AM658043SF-5H 6-8 38 25 51 13 32 1.8 6.0x3.6x0.75

Bias Tees

Part Number Freq Insertion Loss Input Return Loss Ouput Return Loss DC Current RF Power
AM000100PM-BT 0.05-10GHz 0.75dB 15dB 15dB 2.0Amp 30dBm
AM000110PM-BT 0.05-12GHz 0.8dB 18dB 17dB 2.0Amp 30dBm
AM000200PM-BT 300KHz-20GHz 0.75dB 20dB 20dB 0.8Amp 30dBm

Discrete Power GaN HEMTs

Part Number Freq(GHz) Gss(2GHz) P5dB(2GHz) Eff Vds ECCN S-parameters
AM005WN-00-R* DC-18 23dB 33.4dBm 56% 28V EAR99 download
AM012WN-00-R* DC-15 22dB 37.7dBm 55% 28V EAR99 download
AM025WN-00-R* DC-15 21dB 40.5dBm 53% 28V EAR99 download
AM050WN-00-R* DC-15 20dB 43.3dBm 51% 28V 3A001.b.3 download
AM100WN-00-R* DC-15 19dB 46.1dBm 50% 28V 3A001.b.3 download


Model Frequency(GHz) SS Gain P1dB P5dB EffI Vd ECCN
AM00012033TM-SN-R* DC-12 14dB 26dBm 33dBm 15% 28V EAR99
AM00018033TM-SN-R 0.05-18 14dB 22dBm 33dBm 15% 28V EAR99
AM018033TM-SN-R* 0.1-8.0 19dB 26dBm 33dBm 12% 28V EAR99
AM206541TM-SN-R* 2.0-6.5 26dB 38dBm 41dBm 20% 28V EAR99
AM07512041TM-SN-R* 7.5-12.0 21dB 38dBm 41dBm 20% 28V 3A001.b.2.b

GaAs MMICs for VSAT & ITU Applications

Model Frequency(GHz) SS Gain P1dB P3dB EffI Vd ECCN
AM13516042WM-SO-R* 13.5-16.0 22dB 15W 16W 32% 8V 3A001.b.2.b

SPDT T/R Switches

Model Frequency(GHz) SS Gain P1dB P5dB EffI Vd ECCN
AM00014040TM-00* DC-14 1.2dB 40dBm - - -15V EAR99
AM00011040TM-CM-R* DC-11 1.5dB 40dBm - - -15V EAR99
AM007040TM-CM-R* DC-7.0 1.5dB 40dBm 43dBm - -15V EAR99

*Part in-stock
